Description
Replacement K27 turbocharger for selected Zetor UR III tractors fitted with the corresponding turbocharged diesel engine.
This complete turbocharger assembly is designed to replace the original turbocharger, using energy from the engine's exhaust gases to compress incoming air and supply additional air to the engine.
Suitable for replacing a worn, damaged or failed original turbocharger on compatible Zetor tractors.
Part Numbers
-
Zetor: 10022024
-
Alternative reference: 10.022.024
-
Turbocharger model: K27-3060G/6.11
-
Alternative turbo model designation: K27 9201-3060G/6.11
Specifications
-
Component: Engine turbocharger assembly
-
Application: Tractor engine air induction and exhaust system
-
Turbocharger type: K27
-
Turbocharger specification: 3060G/6.11
-
Engine applications: Zetor 1001 and 1201
-
Drive: Exhaust gas-driven turbine
-
Construction: Cast-metal turbine housing and compressor assembly
-
Approximate weight: 8.6–9.0 kg
-
Quantity: 1 complete turbocharger assembly
The weight is based on specialist supplier specifications.
Suitable for Zetor Models
Zetor UR III Series
-
Zetor 8520
-
Zetor 8540
-
Zetor 9520
-
Zetor 9540
Suitable for tractors fitted with the corresponding K27-3060G/6.11 turbocharger and engine arrangement.
Function
The turbocharger uses exhaust gas energy to drive a turbine connected to a compressor.
The compressor increases the amount of air entering the engine, supporting efficient combustion and the engine's designed power output.
A correctly functioning turbocharger is important for maintaining engine performance and efficiency.
Quantity
1 x Complete turbocharger assembly – 10022024.
Oil feed pipes, oil return pipes, mounting gaskets, bolts and additional fittings are not included unless specifically supplied with the item.
Important Fitment Information
Zetor tractors can be fitted with different turbochargers depending on tractor model, production year, engine type and specification.
This turbocharger is intended for compatible Zetor UR III tractors fitted with the corresponding K27-3060G/6.11 turbocharger arrangement.
Please check Zetor part number 10022024, the turbocharger identification plate, turbine housing, compressor housing, oil connections, mounting flanges and photographs against your original turbocharger before ordering.
This turbocharger should not be confused with the different C14-series turbochargers or K27 variants fitted to other Zetor tractors.
Before fitting a replacement turbocharger, the engine lubrication system, turbocharger oil feed and return pipes, air intake system and exhaust connections should be checked for contamination, blockages or other faults.
Installation should be carried out in accordance with the appropriate service instructions.
If you are unsure about compatibility, please contact us with your tractor model, serial number, engine details and photographs of the existing turbocharger and identification plate.
